Products

SO8N socket
SO8N socket
SO8N socket
SO8N socket
SO8N socket
SO8N socket

SO8N Socket

$6.00

Solderless SO8N socket-to-DIP adapter for breadboards. The socket lets you swap chips as many times as needed, without soldering. Compatible with all INACKS 8-pin chips.
IS3710 I2C DMX receiver chip
IS3710 I2C DMX receiver chip diagram
IS3710 I2C DMX receiver chip detailed diagram
IS3710 I2C DMX receiver chip schematic
IS3710 I2C DMX receiver chip
IS3710 I2C DMX receiver chip internal diagram
IS3710 I2C DMX receiver chip memory map
IS3710 I2C DMX receiver chip pinout

I2C DMX Receiver – IS3710

Price range: $1.95 through $3.00

The DMX Receiver Chip (IS3710) instantly buffers an entire DMX512 universe, providing reliable channel data via a simple I2C interface. Eliminate complex timing constraints and save valuable firmware engineering time.
SKU: IS3710-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS3720 I2C DMX+RDM receiver chip
IS3720 I2C DMX+RDM receiver chip diagram
IS3720 I2C DMX+RDM receiver chip overview
IS3720 I2C DMX+RDM receiver chip pinout
IS3720 I2C DMX+RDM receiver chip example schematic
IS3720 I2C DMX+RDM receiver chip
IS3720 I2C DMX+RDM receiver chip, front view

I2C DMX+RDM Receiver Chip – IS3720

Price range: $1.95 through $3.00

512-channel DMX receiver and RDM responder in a single SO8N chip. Read DMX data over I2C while the IS3720 handles RDM discovery, addressing and identify requests under your own brand. No DMX or RDM stack to write.
SKU: IS3720-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS4310 I2C Modbus RTU slave chip
IS4310 I2C Modbus RTU slave chip diagram
IS4310 I2C Modbus RTU slave chip memory map
IS4310 I2C Modbus RTU slave chip memory map
IS4310 I2C Modbus RTU slave chip flyer
IS4310 datasheet front page
IS4310 I2C Modbus RTU slave chip
IS4310 I2C Modbus RTU slave chip RS232 schematic
IS4310 I2C Modbus RTU slave chip isolated RS485 schematic
IS4310 I2C Modbus RTU slave chip RS485 schematic

I2C Modbus RTU Slave Chip – IS4310

Price range: $1.95 through $3.00

The IS4310 chip is a Modbus RTU Slave chip with up to 500 holding registers available for your project. It connects to your microcontroller via I2C. No libraries needed. Ideal for sensors, actuators, or mixed setups.
SKU: IS4310-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS4350 Modbus TCP/IP server chip
IS4350 Modbus TCP/IP server chip general diagram
IS4350 Modbus TCP/IP server chip

Modbus TCP/IP Server Chip – IS4350

$6.83

The IS4350 is a Modbus TCP/IP server chip with I2C interface. Your microcontroller reads and writes its 65,500 Holding Registers with standard I2C commands: no TCP/IP stack or Modbus library required. Connects to Ethernet through an external LAN8742A PHY. Ideal for Modbus TCP/IP sensors, actuators and remote I/O.
SKU: IS4350-L64
IS3752 multiple I2C addressable LED controller chip
IS3752 multiple I2C addressable LED controller chip general diagram
IS3752 multiple I2C addressable LED controller chip memory map example
IS3752 multiple I2C addressable LED controller chip pinout
IS3752 multiple I2C addressable LED controller chip general diagram
IS3752 multiple I2C addressable LED controller chip internal diagram
IS3752 multiple I2C addressable LED controller chip memory map
IS3750 I2C addressable LED controller chip

Multiple I2C Addressable LED Controller Chip – IS3752

Price range: $1.95 through $3.00

Easily control 1200x addressable LEDs from your microcontroller via I2C using the IS3752.
Up to 25 different configurable I2C slave addresses.
This chip is the successor to the IS3750, which supported only a single slave address.

SKU: IS3752-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS3750 I2C addressable LED controller chip
IS3750 I2C addressable LED controller chip overview
IS3750 I2C addressable LED controller chip memory map
IS3750 I2C addressable LED controller chip memory map details
IS3750 I2C addressable LED controller chip block diagram
IS3750 I2C addressable LED controller chip pinout
IS3750 I2C addressable LED controller chip general schematic
IS3750 I2C addressable LED controller chip

Single I2C Addressable LED Controller Chip – IS3750

Price range: $1.95 through $3.00

Easily control addressable LEDs from your microcontroller via I2C using the IS3750.
Only one fixed I2C slave address possible. For multiple configurable slave addresses, refer to the IS3752.

SKU: IS3750-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS3715 I2C DMX controller chip
IS3715 I2C DMX controller chip overview
IS3715 I2C DMX controller chip memory map
IS3715 I2C DMX controller chip overview
IS3715 I2C DMX controller chip block diagram
IS3715 I2C DMX controller chip pinout
IS3715 I2C DMX controller chip schematic
IS3715 I2C DMX controller chip

I2C DMX Controller – IS3715

Price range: $1.95 through $3.00

This is a DMX protocol controller chip. It continuously generates DMX data (all 512 channels) based on what you write to its internal memory map via I2C.
SKU: IS3715-S8
Select options This product has multiple variants. The options may be chosen on the product page
IS4320 I2C Modbus RTU master chip
IS4320 I2C Modbus RTU master chip diagram
IS4320 I2C Modbus RTU master chip pinout
IS4320 I2C Modbus RTU master chip memory map
IS4320 I2C Modbus RTU master chip internal blocks
IS4320 I2C Modbus RTU master chip bus topology
IS4320 I2C Modbus RTU master chip cable routing
IS4320 I2C Modbus RTU master chip RS485 schematic
IS4320 I2C Modbus RTU master chip

I2C Modbus RTU Master Chip – IS4320

Price range: $1.95 through $3.00

The IS4320 is a chip with an integrated Modbus RTU Master stack. Your microcontroller communicates through I2C, while the chip manages frame generation, timing, and CRC. It supports Function Codes 1, 2, 3, 4, 15, and 16, making integration straightforward and significantly reducing development time.
SKU: IS4320-S8
Select options This product has multiple variants. The options may be chosen on the product page
